Solis S6-GC3P grid-tied inverter (25–36) kW · three-phase
Solis S6-GC3P (25–36 kW) is a new-generation three-phase grid-tied inverter from the S6 series for commercial (C&I) solar power plants and large residential sites. It features 3–4 MPPT trackers supporting high-current panels (up to 16 A per string / 32 A per MPPT), delivers an efficiency of up to 98.5% and supports intelligent AFCI arc-fault protection together with the Zero Export function.
Models
1 / 5
1 / 5
Overview
Solis S6-GC3P (25–36 kW) is a new-generation three-phase grid-tied inverter (sixth S6 series) for building commercial solar power plants. The model is designed to cut electricity costs by offsetting a company's self-consumption or by operating under the feed-in tariff. It is ideal for medium-sized production sites, warehouse complexes, vehicle service stations, hotels and commercial buildings.
The inverter converts generation from the PV modules directly into the site's three-phase grid without any battery bank. This makes the system exceptionally reliable and shortens the return-on-investment period.
The S6 series features an improved architecture: 3 or 4 independent MPPT trackers supporting increased input current per string, enabling operation with the most powerful modern solar modules (600+ W) and efficient PV array layouts on complex roofs with mixed orientations.
Solis S6-GC3P stands out with maximum efficiency of up to 98.5%, a low start-up voltage for a longer working day, IP66 ingress protection, integrated arc-fault detection (AFCI), Type II surge protection on the DC and AC sides, Zero Export to limit generation fed into the external grid, and intelligent SolisCloud monitoring.
Key specifications
-
Power range (kW)
25–36
-
Grid phases
Three-phase (380 V)
-
Number of MPPT trackers
3–4 MPPT
-
Built-in monitoring
Wi-Fi, 4G
Key features
-
String current up to 21 A
-
Inverter load ratio > 150%
-
AFCI protection actively reduces the risk of fire
-
Intelligent flow control and smart I-V curve scanning
-
24-hour monitoring of consumed load
-
Two independent RS485 ports supporting communication with multiple devices
Technical specifications
Models
SKU: S6-GC3P25K-NV-ND
DC input
- Recommended maximum input power
- 37.5 kW
- Recommended maximum input power
- 45 kW
- Recommended maximum input power
- 49.5 kW
- Recommended maximum input power
- 54 kW
- Maximum input voltage
- 1100 V
- Rated voltage
- 600 V
- Start-up voltage
- 180 V
- MPPT voltage range
- 180 - 1000 V
- Max. input current
- 42 A / 42 A / 42 A
- Max. short-circuit current
- 52.5 A / 52.5 A / 52.5 A
- Number of MPPTs / max. inputs per MPPT
- 3 / 6
AC output
- Rated output power
- 25 kW
- Rated output power
- 30 kW
- Rated output power
- 33 kW
- Rated output power
- 36 kW
- Max. apparent output power
- 25 kVA
- Max. apparent output power
- 30 kVA
- Max. apparent output power
- 33 kVA
- Max. apparent output power
- 36 kVA
- Rated grid voltage
- 3/N/PE, 220 V / 380 V, 230 V / 400 V
- Rated grid frequency
- 50 Hz / 60 Hz
- Rated grid output current
- 38.0 A / 36.1 A
- Rated grid output current
- 45.6 A / 43.3 A
- Rated grid output current
- 50.1 A / 47.6 A
- Rated grid output current
- 54.7 A / 52 A
- Max. output current
- 38.0 A / 36.1 A
- Max. output current
- 45.6 A / 43.3 A
- Max. output current
- 50.1 A / 47.6 A
- Max. output current
- 54.7 A / 52 A
- Power factor
- > 0.99 (-0.8 to +0.8)
- THDi
- < 3%
Efficiency
- Maximum efficiency
- 98.5%
- European efficiency
- 98%
Protection
- DC reverse polarity protection
- Yes
- Short-circuit protection
- Yes
- Overcurrent protection
- Yes
- Surge protection
- Yes
- Grid monitoring
- Yes
- Anti-islanding protection
- Yes
- Temperature protection
- Yes
- String monitoring
- Yes
- I-V curve measurement
- Yes
- Multi-peak scanning
- Yes
- Built-in AFCI 2.0 module
- Optional
- Built-in DC disconnector
- Yes
General data
- Dimensions (W × H × D)
- 355 × 625 × 250 mm
- Weight
- 25.3 kg
- Weight
- 25.5 kg
- Weight
- 26.5 kg
- Weight
- 26.5 kg
- Inverter topology
- Transformerless
- Self-consumption
- < 1 W
- Ambient operating temperature range
- -25 ~ +60°C
- Relative humidity
- 0 - 100%
- Ingress protection (IP)
- IP66
- Noise level (typical)
- ≤ 55 dB(A)
- Cooling method
- Intelligent fan cooling
- Max. operating altitude
- 4000 m
- Grid connection standard
- UNE 206006/UNE 206007-1, CEI 0-21, C10/11, NRS 097-2-1, TOR, EIFS 2018.2, IEC 62116, IEC 61727,
- Safety / EMC standard
- IEC/EN 62109-1/-2, IEC/EN 61000-6-1/-2/-3/-4
Features
- DC connection
- MC4 connector
- AC connection
- OT terminal
- Display
- LED indicator and Bluetooth + app
- Communication
- Standard: RS485×2; optional: Wi-Fi, 4G, DRM
Documentation and certificates
-
DownloadDatasheet
Мережевий інвертор Solis S6-GC3P (25–36) кВт · трифазний.pdf
-
DownloadUser manual
Мережевий інвертор Solis S6-GC3P (25–36) кВт · трифазний_інструкція1.pdf
-
DownloadCertificate 1
Мережевий інвертор Solis S6-GC3P (25–36) кВт · трифазний_сертифікат1.pdf
-
Download
Certificate 2
Мережевий інвертор Solis S6-GC3P (25–36) кВт · трифазний_сертифікат2.pdf
-
Download
Certificate 3
Мережевий інвертор Solis S6-GC3P (25–36) кВт · трифазний_сертифікат3.pdf
-
Download
Certificate 4
Мережевий інвертор Solis S6-GC3P (25–36) кВт · трифазний_сертифікат4.pdf
-
Download
Certificate 5
Мережевий інвертор Solis S6-GC3P (25–36) кВт · трифазний_сертифікат5.pdf
-
Download
Certificate 6
Мережевий інвертор Solis S6-GC3P (25–36) кВт · трифазний_сертифікат6.pdf
Frequently asked questions
-
Start from the site's average daily consumption and the peak load the inverter has to carry in off-grid mode. The power range of each modification and the recommended PV array size for it are listed in the product card under "Key specifications" — for a precise selection, contact a Solis dealer or use the form below.
-
The list of validated batteries is published on the product page — in the compatible-equipment section, where one has already been compiled for that model. The voltage range (LV or HV, depending on the series) is stated in the technical specifications either way. If there is no list, or the battery you need is not on it, contact the Solis Ukraine technical department — compatibility should be confirmed separately.
-
Most Solis hybrid and off-grid inverters support connecting a generator with automatic start-up when the battery is discharged. Whether a specific model has this function, and how it is wired, is stated under "Key features" and in the "Technical specifications" table of the product card.
-
It depends on the series: single-phase models are designed for a 220 V grid, three-phase models for 380/400 V. The exact connection type for a given product is stated in the "Grid phases" card under "Key specifications".
-
Solis equipment carries the manufacturer's warranty, which in Ukraine is administered by official dealers and authorised service centres. The exact term and conditions are stated on the warranty card and on the device's rating plate — for registration and the claim procedure, see the Support section.
Didn't find your answer?
The Solis Ukraine technical department advises on equipment compatibility, wiring diagrams and system configuration.
